Heavy duty cash register plotter paper rolls thermal paper slitting machine

HX1200/1400FQ

Heavy slitting machine

This machine is a high-end slitting machine developed and produced using the world's most advanced heavy-duty slitting machine technology. The entire machine adopts cast iron wall panel and base, adopts up and down sliding cylinder paper pressing structure, and equipped with an automatic tension control system and a touch screen operation interface.

Technical feature

Accurate slitting, fast speed, neat slitting end face, adjustable paper roll tightness, automatic paper feeding, automatic length or sheet counting(tracking), automatic tension, automatic marking, waste blowing disposal, automatic push out paper roll, automatic cutting, automatic glue spraying, spindle auto withdraw, adjustable elastic and tight edges, PLC control of the entire machine, spiral type pressure roller, paper bow roller, one key operation etc.

Jumbo paper roll slitter rewinder thermal paper slitting machine

HX1200FQ   Slitting machine

Product Introduction:

PLC control system, automatic tension, stepless variable frequency speed regulation, encoder meter counting, ensuring accurate meter counting. The tension of the paper roll can be adjust arbitrarily, with accurate and fast cutting speed, and the cutting edge face is neat. The overall weight of wall panels ensure smooth operation of the machine.

Printing slitting machine (Single Color)

HX650FQ-Y-1

This machine is our company's high-end product that latest integrates printing and slitting, based on years of production and research and development of similar products, it is equipped with the latest automatic control system, with one click control throughout the entire process and easy operating, adopting fully cast iron wall panels and bases, ensuring stable operation.

Technical feature:

1.clear printing, precise positioning, capable of achieve front and back printing. Printing and slitting in one time.

2. Dying method : hot wind dying.

3.Accurate slitting, fast speed, with neat cutting end faces.

4.Automatic tension control, freely adjust the tension of the paper roll.

5.Automatic paper loading, air shaft.

6.Automatic marking.

7.Automatic length counting, waste blowing disposal.

8.PLC control system, stepless variable frequency speed regulation.

1.The electronic governor can adjust the conveying speed of the conveyor belt arbitrarily .

2.Adopting a double-layer insulation device, the out side surface of the machine will not be too hot.

3.Double layer heat resistant and insulation cord fabric, greatly reducing heat loss.

4.The conveyor chain adopts a 10mm roller and is externally wrapped with temperature resistant silicone tube, which can withstand heavy objects without deformation of the roller. Optional mesh conveyor.

5.Scope of use: PE, PVC, PP, POF and other types of shrink films.

This machine is a new type of perforating and folding machine developed and produced by our company. The entire machine is controlled by PLC and touch screen.The body adopts a new base, which reduces the height of the machine and makes it more convenient and stable to operate. The machine highlights the concepts of “Easy operation” and “steady operation under high speed” in its structural design.

About sealing and cutting part:

This machine can be used for fully automatic online shrinkage packaging of products, using a folded film and sealing the other three sides. The constant temperature heating and sealing system can automatically detect products using photoelectronics, and can choose between automatic feeding and manual feeding modes for sealing PE and POF heat sealing films. The sealing is firm and beautiful, especially suitable for POF sealing and cutting. When changing the product size, only simple adjustments need to be made through the handwheel, without the need to replace any components, reducing product replacement time and making it easier to operate. The adjustable

front-end feeding system and the back-end storage work platform enable the entire machine to operate at high speed and unmanned automatically.

This machine is the latest printing slitting machine developed by our company, which achieves one-time printing slitting and greatly improves work efficiency. The machine has two methods: skip printing and continuous printing, which can meet the different needs of customers; The printing part adopts flexographic water-based ink printing with servo control, which reduces environmental pollution, reduces the potential harm of fire and volatile harmful substances to employees, and also ensures printing accuracy; The whole machine adopts automatic tension, touch screen and PLC control to ensure normal and stable operation of the machine; The whole machine uses cast iron wall panels, making the operation of the machine more stable.
